owners manual VW Tiguan

all ratings: 0 average rating: 5

6. Remove the screws (3) C. 7. Pull the tail light out of the body carefully until the electrical connector is visible. 8. Remove the red locking mechanism ⇒ fig. 207 (1) D as illustrated and disconnect the electrical connector with the lever (2) D pressed down. 9. Lay the tail light on a clean and level surface. Replacing light bulbs 10. Remove the screws (4) E. 11. Remove the bulb holder (3) E from the tail light. 12. Replace burned out tail light, brake light (5) F or turn signal bulbs (6) F with bulbs that are identical to the ones being replaced. 13. Insert the bulb holder in the tail light and screw it in E. Installing the tail lights 14. Turn the locking mechanism ⇒ fig. 206 (1) A 90 ° clockwise until it stops. 15. Insert the electrical connector into the bulb holder until it clicks into place. Press the red locking mechanism ⇒ fig. 207 (1) D back in. 16. Insert the tail light into the opening on the body carefully. 17. Hold the tail light in the correct position with one hand and tighten the screws with the other hand (3) C. 18. Insert the trim panel ⇒ fig. 206 (2) B into its original position, first at the bottom and then at the top. 19. Close the side storage compartment in the luggage compartment. 20. Close the rear hatch LEDs in the rear taillights Changing LEDs is not possible without dismantling vehicle components. Contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Taillights with LEDs may also have some “standard” light bulbs. These bulbs can be replaced. Different models may have different lights, and the location and design of covers, bulb holders, and bulbs may be in a different location than shown in the illustrations.
