text version of content this owner's manual page from owners manual to the vehicle Mazda Tribute, year of production 2000 - 2011:

Climate Controls Climate Controls MANUALHEATINGANDAIRCONDITIONINGSYSTEM (IF EQUIPPED) 5 1 1. A/C: Press to activate A/C. The indicator light will illuminate to indicate A/C is functioning. 2. Temperature selection: Controls the temperature of the airflow in the vehicle. 3. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each432 control. : Distributes air through the instrument panel vents. : Distributes air through the instrument panel vents and the floor vents. O(OFF): The fan will not operate. : Distributes air through the floor vents. : Distributes air through the windshield defroster vents and floor vents. : Distributes air through the windshield defroster vents. 4. Fan speed and recirculated/outside air control: Turned to the right, controls the volume of outside air coming into the vehicle. Turned to the left, recirculates air through the instrument panel registers. This mode is more economical and efficient. May reduce undesirable odors from entering the vehicle. 5. Rear defroster: Press to clear the rear window of thin ice and fog. The indicator light will illuminate when the rear defroster is activated. Ensure that the ignition is in the ON position to operate. The defroster turns off automatically after 15 minutes or when the ignition is turned to the OFF position. To manually turn off the defroster before 15 minutes have passed, push the control again. WARNING: Extended operation of the climate control system in a recirculated air mode may lead to a reduction in air quality in the cabin. The air in the cabin should be periodically refreshed by selecting settings other than recirculated air. 31 REVIEW COPY 2005 Mazda Tribute (j14), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus)
