owners manual Audi R8

owners manual Audi R8 - year of production: 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015 - Audi R8 I 1 owners manual EN

Document: pdf (8.51 MB) 210 pages
all ratings: 0 average rating: 5
text version of content this owner's manual page from owners manual to the vehicle Audi R8, year of production 2006 - 2015:
document_0900452a816e6cc9.book Seite 198 Mittwoch, 21. Februar 2007 1:32 13 198 Performance, weights and dimensions Performance, weights and dimensions R8 4.2 quattro Engine oil Engine data LongLife Service VW 504 00 Inspection Service VW 502 00, VW 504 00 Power output 309 kW at 7800 rpm Engine oil capacity approx. 10 litres Maximum torque 430 Nm at 4500 to 6000 rpm (including filter change) Cylinders, capacity 3 8 cylinders, 4163 cm Valves per cylinder 4 MG = Manual gearbox / AG = Automatic gearbox (R tronic) Bore mm 84.5 1) With slight loss of power Stroke mm 92.8 Compression ratio 12.5:1 Dimensions Firing order 1-5-4-8-6-3-7-2 Fuel Super Plus unleaded 98 RON or Length mm 4431 premium unleaded not less than 1) Width mm 1904 95RON Width across mirrors mm 2029 Performance figures Height, unladen1) mm 1252 Maximum speed km/h 301 Turning circle diameter m 11.80 Acceleration from 0 - 100 km/h sec.4.6 1) Acceleration from 0 - 200 km/h sec.14.9 The height of the vehicle depends on the tyres and suspension. Take care not to damage low-mounted parts of the car (such as the Weights spoiler or exhaust system) on steep ramps, uneven road surfaces or roadside kerbs, etc. Gross vehicle weight kg MG = 1860 AG = 1865 Take particular care if the car has lowered (sports) suspension or if Kerb weight (unladen weight)kg MG = 1560 AG = 1565 it is fully laden. Maximum front axle weightkg MG = 890 AG = 890 Maximum rear axle weight kg MG = 1050 AG = 1055
